| Processor |
| Processor manufacturer |
Intel |
| Processor family |
Intel® Xeon® Silver |
| Processor generation |
3rd generation Intel® Xeon® scalable |
| Processor model |
4309Y |
| Processor frequency |
2.8 GHz |
| Maximum turbo frequency of processor |
3.6 GHz |
| Efficient core base frequency |
0.0028 GHz |
| Performance core base frequency |
2.8 GHz |
| Number of processor cores |
8 |
| Processor cache |
12 MB |
| Number of installed processors |
1 |
| Maximum internal memory supported by processor |
32 GB |
| Memory |
| Internal memory |
16 GB |
| Internal memory type |
DDR4-SDRAM |
| Type of buffered memory |
Registered (buffered) |
| Memory ranking |
2 |
| Memory slots |
16x DIMM |
| Memory layout |
1 x 16 GB |
| Memory data transfer rate |
3200 MT/s |
| Maximum internal memory |
64 GB |
| Storage media |
| Total storage capacity |
480 GB |
| Number of installed SSDs |
1 |
| SSD capacity |
480 GB |
| SSD interfaces |
SATA III |
| SSD form factor |
2.5" |
| Supported SSD sizes |
3.5" |
| Number of supported SSDs |
8 |
| RAID support |
Yes |
| Supported RAID controllers |
PERC H755 |
| Hot-plug support |
Yes |
| Type of optical drive |
No |
| Internal drive bays |
8 |
| Supported storage drive interfaces |
SAS, SATA |
| Drive writes per day (DWPD) |
1 |
| Adapter storage drive included |
Yes |
| Type of adapter storage drive |
2.5" - 3.5" |
| Graphics |
| Built-in graphics adapter |
No |
| On-board graphics adapter model |
Not available |
| Network |
| Ethernet LAN |
Yes |
| Wiring technology |
10/100/1000Base-T(X) |
| Ethernet interface type |
Gigabit Ethernet |
| Ports & interfaces |
| Number of Ethernet LAN (RJ-45) ports |
2 |
| Number of USB 2.0 ports |
2 |
| Number of USB 3.2 Gen 1 (3.1 Gen 1) Type A ports |
2 |
| VGA (D-Sub) port(s) |
1 |
| Serial port(s) |
1 |
| Number of power cables |
1 |
| Design |
| Chassis type |
Tower (5U) |
| Product color |
Black |
| Bezel |
Yes |
| Performance |
| Remote management |
iDRAC9, Enterprise 15G |
| Software |
| Operating system included |
No |
| Compatible operating systems |
Canonical Ubuntu Server LTS
● Citrix Hypervisor
Microsoft Windows Server with Hyper-V
Red Hat Enterprise Linux
SUSE Linux Enterprise Server
VMware ESXi |
| Power |
| Redundant power supply |
No |
| Power supply |
700 W |
| Number of main power supplies |
1 |
| Power supply input voltage |
200 - 240 V |
| Power cable length |
2 m |
| Power cable connector 1 |
C13 plug |
| Power cable current |
10 A |
| Environmental requirements |
| Operating temperature (T-T) |
10 - 35 °C |
| Storage temperature |
-40 - 65 °C |
| Storage humidity |
5 - 95 percent |
| Operating altitude |
0 - 3048 m |
| Storage altitude |
0 - 12000 m |
| Carbon footprint |
| Total Carbon Footprint (kg of CO2e) |
9090 |
| Total carbon emissions, standard deviation (kg CO2e) |
4620 |
| Carbon emissions, production (kg CO2e) |
1095.1 |
| Carbon emissions, logistics (kg CO2e) |
565 |
| Carbon emissions, energy consumption (kg CO2e) |
7390 |
| Carbon emissions, end of life (kg CO2e) |
46.6 |
| Total carbon emissions, excluding use phase (kg CO2e) |
1700 |
| PAIA version |
1.3.2, 2022 |
| Weight and dimensions |
| Width |
200 mm |
| Depth |
680.5 mm |
| Height |
459 mm |
| Other specifications |
| Transfer rate |
6 Gbit/s |
| Bytes per sector |
512 |
