| Processor |
| Processor manufacturer |
Intel |
| Processor family |
Intel Core Ultra 5 |
| Processor generation |
Intel Core Ultra (Series 2) |
| Processor model |
235 |
| Number of processor cores |
14 |
| Processor thread count |
14 |
| Maximum processor turbo frequency |
5 GHz |
| Performance cores |
6 |
| Efficient cores |
8 |
| Performance-core Max Turbo Frequency |
5 GHz |
| Efficient-core Max Turbo Frequency |
4.4 GHz |
| Performance-core base frequency |
3.4 GHz |
| Efficient-core base frequency |
2.9 GHz |
| Processor cache |
24 MB |
| Processor cache type |
Smart Cache |
| Number of installed processors |
1 |
| Processor base power |
65 W |
| Maximum turbo power |
121 W |
| Neural Processing Unit (NPU) |
| Neural Processing Unit (NPU) |
Intel AI Boost |
| Sparsity support |
Yes |
| Support for Windows Studio effects |
Yes |
| AI software frameworks supported by NPU |
DirectML, OpenVINO, Windows ML, ONNX RT, WebNN |
| Total processor performance up to |
27 TOPs |
| NPU performance up to |
13 TOPs |
| GPU performance up to |
6 TOPs |
| Memory |
| Internal memory |
16 GB |
| Maximum internal memory |
64 GB |
| Internal memory type |
DDR5-SDRAM |
| Memory layout |
1 x 16 GB |
| Memory slots |
2x DIMM |
| Non-ECC |
Yes |
| Memory channel |
Single channel |
| Memory data transfer rate |
5600 MT/s |
| Storage media |
| Total storage capacity |
512 GB |
| Storage media |
SSD |
| Type of optical drive |
No |
| Number of storage drives installed |
1 |
| Total SSD capacity |
512 GB |
| Number of installed SSDs |
1 |
| SSD capacity |
512 GB |
| SSD interfaces |
PCI Express |
| NVMe |
Yes |
| SSD form factor |
M.2 |
| Graphics |
| Dedicated graphics adapter |
No |
| Integrated graphics adapter |
Yes |
| Discrete graphics adapter model |
Not available |
| Internal GPU manufacturer |
Intel |
| Integrated graphics adapter family |
Intel Graphics |
| On-board graphics adapter model |
Intel Graphics |
| Network |
| Ethernet LAN |
Yes |
| Ethernet LAN data transfer rates |
10,100,1000 Mbit/s |
| Wiring technology |
10/100/1000Base-T(X) |
| LAN controller |
Intel® I219-LM |
| Wi-Fi |
Yes |
| Wi-Fi standard |
Wi-Fi 6E (802.11ax) |
| Wi-Fi standards |
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax) |
| WLAN controller manufacturer |
Intel |
| WLAN controller model |
Intel Wi-Fi 6E AX211 |
| Antenna type |
2x2 |
| Antenna design |
Internal |
| Bluetooth |
Yes |
| Ports & interfaces |
| Number of USB 2.0 ports |
4 |
| Number of USB 3.2 Gen 1 (3.1 Gen 1) Type A ports |
3 |
| Number of USB 3.2 Gen 1 (3.1 Gen 1) Type C ports |
1 |
| Number of HDMI ports |
1 |
| HDMI version |
2.1 |
| Number of DisplayPorts |
1 |
| DisplayPort version |
1.4a |
| Number of Ethernet LAN (RJ-45) ports |
1 |
| Combo headphone/microphone port |
Yes |
| Power adapter connection |
Yes |
| Number of USB ports at the back |
4 |
| Number of USB ports at the front |
4 |
| Number of SATA III connectors |
2 |
| Expansion modules |
| PCI Express x1 (Gen 3.x) slots |
2 |
| PCI Express x16 (Gen 3.x) slots |
1 |
| Design |
| Chassis type |
Slim PC |
| Placement support |
Horizontal/Vertical |
| Cable lock slot |
Yes |
| Cable lock slot type |
Kensington |
| Product color |
Black |
| Intel® vPro™ Platform Eligibility |
Yes |
| Performance |
| Market positioning |
Business |
| Audio chip |
Realtek ALC3204 |
| Audio system |
High Definition Audio |
| Trusted Platform Module (TPM) |
Yes |
| Product type |
PC |
| Trusted Platform Module (TPM) version |
2.0 |
| Software |
| Operating system architecture |
64-bit |
| Operating system included |
Windows 11 Pro |
| Trial software |
Activate Your Microsoft 365 For A 30 Day Trial |
| Power |
| Power supply |
180 W |
| Power supply input voltage |
90 - 264 V |
| Power supply input frequency |
47/63 Hz |
| Environmental requirements |
| Operating temperature (T-T) |
10 - 35 °C |
| Storage temperature |
-40 - 65 °C |
| Operating relative humidity (V-V) |
10 - 90 percent |
| Storage humidity |
0 - 95 percent |
| Operating altitude |
-15.2 - 3048 m |
| Storage altitude |
-15.2 - 10668 m |
| Operating vibration |
0.66 G |
| Storage vibration |
1.3 G |
| Shock resistance |
110 G |
| Shock resistance (non-operating) |
160 G |
| Sustainability |
| Sustainability certificates |
ENERGY STAR, EPEAT Climate +, EPEAT Gold |
| Contains no |
PVC/BFR |
| Weight and dimensions |
| Width |
95 mm |
| Depth |
293 mm |
| Height |
303.5 mm |
| Weight |
5.89 kg |
| Package contents |
| Included cables |
AC |
| Display |
| Monitor included |
No |
