| WAN connection |
| Ethernet WAN |
Yes |
| DSL WAN |
No |
| SIM card slot |
No |
| 3G/4G USB modem compatibility |
No |
| Network |
| Network standard |
IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x |
| Ethernet interface type |
Gigabit Ethernet |
| Wiring technology |
10/100/1000Base-T(X) |
| Ethernet LAN, data transfer rates |
10,100,1000 Mbit/s |
| VLAN support |
Yes |
| Traffic control |
Yes |
| Policy-based routing |
Yes |
| Concurrent connections |
150000 |
| Management features |
| Web-based management |
Yes |
| Universal Plug and Play (UPnP) |
Yes |
| Reset button |
Yes |
| Ports & interfaces |
| Number of Ethernet LAN (RJ-45) ports |
5 |
| Number of USB ports |
1 |
| Protocols |
| DMZ support |
Yes |
| Routing protocols |
RIP-1, RIP-2 |
| Management protocols |
Telnet |
| DHCP client |
Yes |
| DHCP server |
Yes |
| Supported network protocols |
TCP/IP, DHCP, ICMP, NAT, PPPoE, SNTP, HTTP, DNS, IPsec, PPTP, L2TP |
| Supported protocols |
IPsec/PPTP/L2TP |
| Security |
| Supported security algorithms |
3DES, 128-bit AES, 192-bit AES, 256-bit AES, DES, MD5, SHA-1 |
| Firewall |
Yes |
| Authentication method |
SHA-1, MD5 |
| URL filtering |
Yes |
| DoS attack prevention |
Yes |
| ARP attack prevention |
Yes |
| Network address translation (NAT) |
Yes |
| System event log |
Yes |
| VPN tunnels quantity |
20 |
| VPN features |
• 20 IPsec VPN Tunnels
• LAN-to-LAN, Client-to-LAN
• Main, Aggressive Negotiation Mode
• DES, 3DES, AES128, AES192, AES256 Encryption Algorithm
• IKEv1/v2
• MD5, SHA1 Authentication Algorithm
• NAT Traversal (NAT-T)
• Dead Peer Detection (DPD)
• Perfect Forward Secrecy (PFS)
• PPTP VPN Server
• 10 PPTP VPN Clients
• 16 Tunnels
• PPTP with MPPE Encryption
• L2TP VPN Server
• 10 L2TP VPN Clients
• 16 Tunnels
• L2TP over IPSec
• OpenVPN Server
• 10 OpenVPN Clients
• 16 OpenVPN Tunnels |
| NAT functionality |
• One-to-One NAT
• Multi-Net NAT
• Virtual Server
• Port Triggering
• NAT-DMZ
• FTP/H.323/SIP/IPSec/PPTP ALG, UPnP |
| Certificates |
| Compliance certificates |
RoHS |
| Package contents |
| Included cables |
AC |
| User manual |
Yes |
| Quick start guide |
Yes |
| Quick installation guide |
Yes |
| Features |
| Flash memory |
128 MB |
| Internal memory |
256 MB |
| Internal memory type |
DRAM |
| Supports Windows |
Windows 10, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows Vista, Windows XP |
| Supports Mac operating system |
MacOS |
| Supports Linux |
Yes |
| Certification |
CE, FCC, RoHS |
| Design |
| Product color |
Black |
| Rack mounting |
Yes |
| Rack capacity |
1U |
| LED indicators |
Activity, LAN, System, USB, WAN |
| Power |
| Power consumption (typical) |
7.94 W |
| Power source type |
AC |
| AC input voltage |
120 - 240 V |
| AC input frequency |
50 - 60 Hz |
| Environmental requirements |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature |
-40 - 70 °C |
| Operating relative humidity (V-V) |
10 - 90 percent |
| Storage humidity |
5 - 90 percent |
| Weight and dimensions |
| Width |
158 mm |
| Depth |
101 mm |
| Height |
25 mm |
| Packaging |
| Package width |
190 mm |
| Package depth |
254 mm |
| Package height |
60 mm |
| Package weight |
650 g |
